21 03 399 1402

Manufacturer Part Number (MPN) 21 03 399 1402
Manufacturer Harting
Short Description HARTING Han 3 A-M-STI-M20, Male insert, 3+PE contacts, 16 A, Screw termination, IP44, IP65, IP67
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Wire Gauge
0.75 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
230/400 Volts
Contact Surface
Silver plated
Insert Material
Polycarbonate
Contact Material
Copper alloy
Pollution Degree
3
Termination Type
Screw termination
Temperature Range
-40 to +125 degrees Celsius
Tightening Torque
0.5 Newton meters
Contact Resistance
Less than 3 milliOhms
Number Of Contacts
3 plus Protective Earth
Flammability Rating
V-0 according to UL 94
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 Kilovolts
Ingress Protection Rating
IP44, IP65, IP67 with appropriate housing

Full Description

The HARTING 21033991402 Han 3 A-M-STI-M20 male insert is a robust solution for heavy-duty power connections. This insert features 3+PE contacts, capable of handling a current of 16 A. The screw termination method ensures a secure and reliable electrical connection. Designed for use in harsh environments, it boasts IP44, IP65, and IP67 protection ratings, safeguarding against dust and water ingress. This insert is ideal for industrial applications requiring dependable power connectivity. As an authorized distributor of HARTING components, Supreme Components International guarantees the authenticity and quality of this product. Trust HARTING and Supreme Components International for your critical connectivity needs.
