21 03 396 1505

Manufacturer Part Number (MPN) 21 03 396 1505
Manufacturer Harting
Short Description HARTING Han 3A-STI-M-M20, Male insert, 3+PE contacts, 16A, M20 cable gland
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Wire Gauge
0.75 to 2.5 square millimeters
Cable Gland
M20
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
230/400 Volts
Material Insert
Polycarbonate
Pollution Degree
3
Surface Contacts
Silver plated
Termination Type
Screw termination
Material Contacts
Copper alloy
Temperature Range
-40 to +125 degrees Celsius
Tightening Torque
0.5 Newton meters
Contact Resistance
Less than or equal to 3 milliOhms
Number Of Contacts
3 plus Protective Earth
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 Kilovolts
Flammability According To Ul94
V-0
Protection Degree According To Dinen60529
IP44

Full Description

The HARTING 21033961505 Han 3A-STI-M-M20 is a robust male insert specifically engineered for demanding heavy-duty power connector applications. This insert features 3+PE contacts, providing a reliable connection for power and grounding. With a 16A current rating, it is suitable for a wide range of industrial applications. The integrated M20 cable gland ensures secure and strain-relieved cable termination, enhancing the overall durability and reliability of the connection. As an authorized distributor of HARTING components, Supreme Components International guarantees the authenticity and quality of this product. This insert is ideal for applications requiring a dependable and rugged power connection solution.
