21 03 339 1301

Manufacturer Part Number (MPN) 21 03 339 1301
Manufacturer Harting
Short Description HARTING Han 3A-HMC-as-M20, axial screw termination, male insert, 3+PE contacts, 16A, 500V, IP44/IP65
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Wire Gauge
0.75 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 10000
Rated Current
16 Amperes
Rated Voltage
500 Volts
Contact Material
Copper alloy
Pollution Degree
3
Termination Type
Axial Screw
Contact Resistance
Less than or equal to 3 milliOhms
Insulator Material
Polycarbonate
Number Of Contacts
3 plus Protective Earth
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Mechanical Robustness
High Mating Cycle
Operating Temperature
-40 to +125 degrees Celsius
Flammability Rating Ul94
V-0
Ingress Protection Rating
IP44, IP65 with appropriate housing

Full Description

The HARTING 21033391301 is a robust Han 3A-HMC-as-M20 male insert, ideal for demanding heavy-duty power connector applications. This insert features axial screw termination, providing a secure and reliable connection for power and grounding. It includes 3+PE contacts, capable of handling 16A and 500V. The IP44/IP65 rating ensures protection against dust and water ingress, making it suitable for harsh environments. This insert is part of the Han series, known for its modularity and durability. Supreme Components International is an authorised distributor of HARTING electronic components, guaranteeing you receive a genuine, high-quality product. Trust Supreme Components International for all your HARTING connector needs.

Looking for more Harting connectors? [Click here to browse all Harting parts]

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.
