21 03 321 1830
HARTING Han 3A-HMC-as-M20, male insert, axial screw termination, M20 cable gland, high mating cycles
Datasheet
21 03 321 1830 Datasheet
Product Description
The HARTING 21033211830 is a robust Han 3A-HMC-as-M20 male insert, specifically engineered for demanding heavy-duty power connector applications. This connector is designed to withstand high mating cycles, ensuring long-term reliability and performance. It features axial screw termination for easy and secure wiring, along with an M20 cable gland for optimal cable protection and strain relief. The 21033211830 is ideal for use in industrial environments where robust and durable connectivity solutions are essential. Supreme Components International is an authorised distributor of HARTING products, guaranteeing the authenticity and quality of this high-performance connector. Trust Supreme Components International for your HARTING connector needs.
Technical Specifications
| Attribute | Description |
|---|---|
| Wire Gauge | 0.75 to 2.5 square millimeters |
| Cable Gland | M20 |
| Elv Compliant | Yes |
| Mating Cycles | Greater than or equal to 10000 |
| Rated Current | 16 Amperes |
| Rated Voltage | 230 Volts |
| Clamping Range | 7 to 13 millimeters |
| Rohs Compliant | Yes |
| Material Insert | Polycarbonate |
| Pollution Degree | 3 |
| Surface Contacts | Silver |
| Termination Type | Axial screw termination |
| Material Contacts | Copper alloy |
| Contact Resistance | Less than or equal to 3 milliOhms |
| Number Of Contacts | 3 plus Protective Earth |
| Insulation Resistance | Greater than 10 to the power of 10 Ohms |
| Operating Temperature | -40 to +125 degrees Celsius |
| Rated Impulse Voltage | 4 kilovolts |
| Inflammability Class According To Ul94 | V-0 |
| Degree Of Protection According To Iec60529 | IP65/IP67 with appropriate housing |
