21 03 302 2000

Manufacturer Part Number (MPN) 21 03 302 2000
Manufacturer Harting
Short Description HARTING Han 3A-STI-M-axial-2.5, Male insert, Axial screw termination, 3 contacts, 16A, 50V, 2.5 mm²
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Color
RAL 7032 (pebble grey)
Material
Polyamide (PA)
Wire Gauge
2.5 square millimeters
Locking Type
None
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
50 Volts
Pollution Degree
3
Termination Type
Axial screw termination
Thermal Endurance
Minus 40 to 125 degrees Celsius
Contact Resistance
Less than or equal to 3 milliOhms
Number Of Contacts
3
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 kilovolts
Flammability According To Ul94
V-0
Degree Of Protection According To Iec60529
IP40

Full Description

The HARTING 21033022000 is a robust male insert from the Han 3A series, ideal for demanding heavy-duty power connector applications. This insert features axial screw termination, ensuring a secure and vibration-resistant connection for long-term reliability. With 3 contacts, it supports a current rating of 16A and a voltage rating of 50V, accommodating a wire size of 2.5 mm². The insert is constructed from durable Polyamide (PA) material and features an IP40 rating, providing protection against solid objects. Its RAL 7032 (pebble grey) color ensures easy identification. Supreme Components International is an authorised distributor of HARTING products, guaranteeing the authenticity and quality of this essential connector component. This product is perfect for industrial environments requiring reliable power connections.
