Home Harting

20 80 010 0002

Manufacturer Part Number (MPN) 20 80 010 0002
Manufacturer Harting
Short Description HARTING Han 10E Base, Cable entry M20, straight, IP44, with protection cover
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Series
Han E
Surface
Powder-coated, grey (RAL 7037)
Material
Aluminium die-cast
Wire Gauge
0.75 to 2.5 square millimeters
Cable Entry
M20
Locking Type
Central Locking Lever
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
500 Volts
Pollution Degree
3
Protection Degree
IP44
Temperature Range
-40 to +125 degrees Celsius
Contact Resistance
Less than 3 milliOhms
Number Of Contacts
10
Termination Method
Screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms

Ordering Information

Parameter
Value
Weight
60 g
Packaging Type
BOX

Full Description

The Harting 20800100002 is a robust Han 10E base designed for rectangular connector systems. This base features a straight cable entry with M20 threading, ensuring a secure and reliable connection for your application. Its IP44 rating provides protection against splashing water from any direction, making it suitable for use in demanding industrial environments. The integrated protection cover offers an additional layer of defense against dust, debris, and other contaminants, extending the lifespan of the connector. This base is ideal for applications requiring a durable and dependable connection point. As an authorized distributor of Harting components, Supreme Components International guarantees the authenticity and quality of this product. Trust Supreme Components International for all your Harting connector needs.

Looking for more Harting connectors? [Click here to browse all Harting parts]

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.
