19 62 816 1141 ML

Manufacturer Part Number (MPN) 19 62 816 1141 ML
Manufacturer Harting
Short Description HARTING Han 16 HPR EasyCon Hood, straight cable entry, M40, with screw locking, IP68
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Series
Han HPR
Material
Aluminium die-cast
Thread Size
M40
Surface Coating
Powder-coated, grey (RAL 7037)
Termination Type
Screw
Locking Mechanism
Screw Locking
Number Of Contacts
16
Cable Diameter Range
19mm to 28mm
Hood Entry Direction
Straight
Ingress Protection Rating
IP68
Operating Temperature Range
-40 Degrees Celsius to +125 Degrees Celsius

Full Description

The HARTING 19628161141ML Han 16 HPR EasyCon hood is a robust solution for demanding power connector applications. This hood features a straight cable entry with M40 threads, simplifying installation and ensuring a secure connection. The screw locking mechanism provides enhanced stability, preventing accidental disconnections. With an IP68 rating, this hood offers exceptional protection against dust and water, making it suitable for harsh environments. Supreme Components International is an authorised distributor of HARTING products, ensuring you receive a genuine, high-quality component. This hood is ideal for industrial machinery, transportation, and other applications requiring reliable and durable power connections. Benefit from HARTING's renowned engineering and Supreme Components International's commitment to quality.

Looking for more Harting connectors? [Click here to browse all Harting parts]

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.
