19 46 210 0293
HARTING Han 16 HPR EasyCon Hood, straight cable entry, M25, with screw locking, IP68
Datasheet
19 46 210 0293 Datasheet
Product Description
The Harting 19462100293 is a robust Han 16 HPR EasyCon hood, ideal for demanding heavy-duty power connector applications. This hood features a straight cable entry with M25 threads, providing a secure and reliable connection point. The screw locking mechanism ensures enhanced stability, preventing accidental disconnections. With an IP68 rating, this hood offers exceptional protection against dust and water ingress, making it suitable for harsh environments. It is designed for use with compatible Harting Han 16 HPR EasyCon inserts. Supreme Components International is an authorized distributor of Harting electronic components, ensuring you receive genuine, high-quality products.
Technical Specifications
| Attribute | Description |
|---|---|
| Series | Han HPR |
| Material | Aluminium die-cast |
| Thread Size | M25 |
| Surface Coating | Powder-coated, grey (RAL 7037) |
| Locking Mechanism | Screw Locking |
| Number Of Contacts | 16 |
| Termination Method | Screw |
| Cable Diameter Range | 9 - 18 mm |
| Hood Entry Direction | Straight |
| Ingress Protection Rating | IP68 |
| Operating Temperature Range | -40 °C ... +125 °C |
Ordering Information
| Attribute | Description |
|---|---|
| WEIGHT | 0.21 kg |
| Packaging Type | BOX |
