19 40 134 0624

Manufacturer Part Number (MPN) 19 40 134 0624
Manufacturer Harting
Short Description HARTING Han 3A-HMC-M-a2-LB-PG11, Male insert, Axial screw termination, PG11, 3+PE contacts, 16A, 400V, HMC
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Wire Gauge
0.75 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 10000
Rated Current
16 Amperes
Rated Voltage
400 Volts
Contact Surface
Silver
Insert Material
Polycarbonate
Contact Material
Copper alloy
Pollution Degree
3
Temperature Range
Negative 40 to Positive 125 degrees Celsius
Contact Resistance
Less than or equal to 3 milliOhms
Number Of Contacts
3 plus Protective Earth
Termination Method
Axial screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Flammability Class According To Ul94
V-0
Protection Degree According To Dinen60529
IP20

Full Description

The Harting 19401340624 is a robust Han 3A-HMC-M-a2-LB-PG11 male insert, ideal for demanding heavy-duty power connector applications. This insert features axial screw termination, simplifying the wiring process and ensuring a secure connection. The PG11 gland provides strain relief and environmental protection. With 3+PE contacts, a current rating of 16A, and a voltage rating of 400V, this connector is suitable for a wide range of industrial applications. The HMC (High Mating Cycle) design ensures durability and reliability even with frequent mating cycles. Supreme Components International is an authorised distributor of Harting products, ensuring you receive a genuine and high-quality component. This connector is designed for optimal performance and longevity in harsh environments.
