Home Harting

19 40 024 0931

Manufacturer Part Number (MPN) 19 40 024 0931
Manufacturer Harting
Short Description HARTING Han Q 4/2-MC male insert, 4+2 contacts, screw termination, 10A, 250V, IP44/IP65
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Wire Gauge
0.14 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 500
Rated Current
10 Amperes
Rated Voltage
250 Volts
Contact Surface
Silver
Insert Material
Polycarbonate
Contact Material
Copper alloy
Pollution Degree
3
Contact Resistance
Less than 3 milliOhms
Number Of Contacts
4 Power Contacts and 2 Signal Contacts
Termination Method
Screw
Flammability Rating
V-0 according to UL 94
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Operating Temperature
-40 to +125 degrees Celsius
Ingress Protection Rating
IP44, IP65 with appropriate housing

Full Description

The Harting 19400240931 is a robust Han Q 4/2-MC male insert, ideal for heavy-duty power connector applications. This insert features 4+2 contacts, providing versatile connectivity options. The screw termination method ensures a secure and reliable electrical connection, minimizing downtime and maximizing performance. With a current rating of 10A and a voltage rating of 250V, this connector is suitable for a wide range of industrial applications. Its IP44/IP65 rating offers protection against dust and water, making it suitable for harsh environments. Supreme Components International is an authorised distributor of Harting components, ensuring you receive a genuine and high-quality product. This connector is designed for easy installation and long-lasting durability, making it a cost-effective solution for your power connectivity needs.

Looking for more Harting connectors? [Click here to browse all Harting parts]

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.
