19 34 010 0271

Manufacturer Part Number (MPN) 19 34 010 0271
Manufacturer Harting
Short Description HARTING Han 3A-HMC-as-M20, axial screw termination, male insert, 10A, 250V, IP40, M20 cable gland
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Material
Polycarbonate
Wire Gauge
0.14 to 2.5 square millimeters
Cable Gland
M20
Locking Type
Screw Locking
Mating Cycles
Greater than or equal to 500
Rated Current
10 Amperes
Rated Voltage
250 Volts
Wire Gauge Awg
26 to 14 AWG
Material Insert
Polycarbonate
Pollution Degree
3
Surface Contacts
Silver
Termination Type
Axial Screw
Material Contacts
Copper alloy
Contact Resistance
Less than or equal to 3 milliohms
Number Of Contacts
10
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Operating Temperature
-40 to +125 degrees Celsius
Fire Protection According To Ul94
V-0
Degree Of Protection According To Iec60529
IP40

Full Description

The HARTING 19340100271 is a robust Han 3A-HMC-as-M20 male insert, ideal for demanding heavy-duty power connector applications. This insert features axial screw termination, providing a reliable and secure electrical connection. It is rated for 10A and 250V, making it suitable for a variety of power transmission needs. The IP40 protection ensures resistance against solid objects. Designed for use with M20 cable glands, this insert offers easy and secure cable entry. As an authorized distributor of HARTING products, Supreme Components International guarantees the authenticity and quality of this component. Trust HARTING and Supreme Components International for your connector needs.
