09 40 000 9851

Manufacturer Part Number (MPN) 09 40 000 9851
Manufacturer Harting
Short Description HARTING Han 1A-STI-M-M20-SC-C, Male connector insert, M20 cable gland, Crimp termination
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Series
Han 1A
Wire Gauge
0.14 to 2.5 square millimeters
Cable Entry
M20
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
50 Volts
Wire Gauge Awg
26 to 14 AWG
Housing Material
Polyamide (PA)
Pollution Degree
3
Contact Resistance
Less than or equal to 3 milliOhms
Number Of Contacts
4
Termination Method
Crimp
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Operating Temperature
-40 to +85 degrees Celsius
Flammability According To Ul94
V-0
Degree Of Protection According To Iec60529
IP20 (when mated)

Full Description

The Harting 09400009851 is a Han 1A-STI-M-M20-SC-C male connector insert designed for demanding industrial environments. This rectangular connector features a M20 cable gland for secure cable entry and crimp termination for reliable electrical connections. As an authorized distributor of Harting components, Supreme Components International guarantees the authenticity and quality of this product. The robust design ensures durability and long-lasting performance. This connector is suitable for a wide range of applications requiring a dependable and secure connection. Benefit from Harting's renowned engineering and Supreme Components International's commitment to providing genuine electronic components. Choose the 09400009851 for your connectivity needs.
