09 38 012 3002

Manufacturer Part Number (MPN) 09 38 012 3002
Manufacturer Harting
Short Description HARTING Han 3A-HMC-M-axial-crimp, male insert, 12 contacts, crimp termination, axial screw termination, with coding
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Color
Pebble Grey (RAL 7032)
Gender
Male
Series
HAN 3A
Material
Polycarbonate
Wire Gauge
0.14 to 2.5 Square Millimeters
Locking Type
Screw Locking
Mating Cycles
Greater Than or Equal to 10000
Rated Current
16 Amperes
Rated Voltage
230 Volts
Connector Type
Insert
Contact Surface
Silver (Ag)
Contact Material
Copper Alloy
Pollution Degree
3
Protection Degree
IP20
Number Of Contacts
12
Termination Method
Crimp
Working Temperature
-40 to +125 Degrees Celsius
Insulation Resistance
Greater Than 10 to the Power of 10 Ohms
Flammability According To Ul 94
V-0

Full Description

The HARTING 09380123002 is a Han 3A-HMC-M male insert, specifically engineered for demanding heavy-duty power connector applications. This insert features 12 contacts, ensuring ample connectivity for various power and signal transmission needs. The crimp termination method provides a secure and reliable electrical connection, while the axial screw termination adds an extra layer of stability and strain relief. The insert also incorporates coding to prevent incorrect mating, ensuring proper functionality and safety. Supreme Components International is an authorised distributor of HARTING products, guaranteeing that you receive a genuine, high-quality component. This robust connector insert is ideal for use in industrial machinery, automation systems, and other applications where reliable power connections are critical. Its durable construction and secure termination methods ensure long-lasting performance in harsh environments.
