09 33 024 2772
Han 24ES-STI-S 24+PE insert, male, screw terminals
Datasheet
09 33 024 2772 Datasheet
Product Description
The HARTING 09 33 024 2772 is a robust Han 24ES-STI-S male insert, specifically engineered for demanding heavy-duty connector applications. This insert features 24+PE poles, providing comprehensive connectivity for power and signal transmission. The screw terminals offer a secure and reliable method for wire termination, ensuring stable electrical connections even in harsh environments. Supreme Components International is an authorised distributor of HARTING, guaranteeing that you receive a genuine, high-quality product. This insert is ideal for use in industrial machinery, automation systems, and other applications where dependable and durable connectivity is essential. Its rugged design and high-performance capabilities make it a perfect choice for ensuring uninterrupted operation and long-term reliability. Benefit from easy installation and a long service life with this HARTING connector insert. Supreme Components International ensures product authenticity and quality.
Technical Specifications
| Attribute | Description |
|---|---|
| Gender | Male |
| Wire Gauge | 0.5 to 2.5 Square Millimeters |
| Mating Cycles | Greater than or Equal to 500 |
| Rated Current | 16 Amperes |
| Rated Voltage | 500 Volts |
| Contact Surface | Silver Plated |
| Insert Material | Polycarbonate |
| Contact Material | Copper Alloy |
| Pollution Degree | 3 |
| Temperature Range | -40 to +125 Degrees Celsius |
| Contact Resistance | Less than 1 MilliOhm |
| Number Of Contacts | 24 Plus Protective Earth |
| Termination Method | Screw |
| Insulation Resistance | Greater than 10 to the Power of 10 Ohms |
| Flammability Class According To Ul94 | V-0 |
| Protection Degree According To Dinen60529 | IP20 |
