HARTING Han 24E Inserts - Male, 24+PE, Screw Termination, 16A, 500V
Datasheet
09 30 024 0751 Datasheet
Product Description
The HARTING 09300240751 is a robust male insert from the Han 24E series, specifically engineered for demanding heavy-duty power connector applications. This insert features 24+PE (Protective Earth) contacts, providing a comprehensive solution for power and grounding connections. The screw termination method ensures a secure and dependable electrical connection, minimizing the risk of disconnection in harsh environments. With a current rating of 16A and a voltage rating of 500V, this insert is well-suited for various industrial applications requiring reliable power transmission. As an authorized distributor of HARTING components, Supreme Components International guarantees the authenticity and quality of this product. Choose HARTING for dependable connectivity solutions.
Technical Specifications
| Attribute | Description |
|---|---|
| Gender | Male |
| Material | Polycarbonate |
| Wire Gauge | 0.5 to 2.5 square millimeters |
| Current Rating | 16 Amperes |
| Voltage Rating | 500 Volts |
| Pollution Degree | 3 |
| Contact Resistance | Less than 1 milliOhm |
| Number Of Contacts | 24 plus Protective Earth |
| Termination Method | Screw |
| Flammability Rating | UL 94 V-0 |
| Insulation Resistance | Greater than 10 to the power of 10 Ohms |
