09 30 010 2261

Manufacturer Part Number (MPN) 09 30 010 2261
Manufacturer Harting
Short Description HARTING Han 10A-STI-M, male insert, 10 contacts, screw termination, 10A, 250V, IP44
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Material
Polycarbonate
Wire Gauge
0.14 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 500
Rated Current
10 Amperes
Rated Voltage
250 Volts
Pollution Degree
3
Temperature Range
-40 to +125 Degrees Celsius
Contact Resistance
Less than or equal to 3 milliOhms
Number Of Contacts
10
Termination Method
Screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Flammability According To Ul94
V-0
Degree Of Protection With Mating Face
IP44

Full Description

The HARTING 09 30 010 2261 is a robust Han 10A-STI-M male insert, ideal for heavy-duty connector applications requiring reliable and secure connections. This insert features 10 contacts and utilizes a screw termination method, ensuring a strong and durable electrical connection. With a current rating of 10A and a voltage rating of 250V, it is suitable for a wide range of industrial applications. The IP44 protection rating provides protection against solid objects and splashing water, making it suitable for use in demanding environments. As an authorized distributor of Harting products, Supreme Components International guarantees the authenticity and quality of this product. Choose the HARTING 09 30 010 2261 for your heavy-duty connector needs.
