09 30 010 0752

Manufacturer Part Number (MPN) 09 30 010 0752
Manufacturer Harting
Short Description HARTING Han 10A-STI-M, male insert, 10 contacts, screw termination, 10A, 250V, IP44
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Gender
Male
Material
Polycarbonate
Wire Gauge
0.14 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 500
Current Rating
10 Amperes
Voltage Rating
250 Volts
Pollution Degree
3
Protection Degree
IP44
Temperature Range
-40 to +125 degrees Celsius
Contact Resistance
Less than 3 milliOhms
Number Of Contacts
10
Termination Method
Screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 kilovolts
Flammability Rating Ul94
V-0

Full Description

The HARTING 09300100752 is a robust Han 10A-STI-M male insert, ideal for demanding heavy-duty power connector applications. This insert features 10 contacts, providing ample connections for various power and signal requirements. The screw termination method ensures a secure and reliable connection, minimizing downtime and maximizing performance. With a current rating of 10A and a voltage rating of 250V, this insert is suitable for a wide range of industrial applications. The IP44 rating offers protection against solid objects and splashing water, making it suitable for use in harsh environments. Supreme Components International is an authorised distributor of HARTING, ensuring you receive a genuine, high-quality product.

Looking for more Harting connectors? [Click here to browse all Harting parts]

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.
