Home Harting

09 30 010 0522

Manufacturer Part Number (MPN) 09 30 010 0522
Manufacturer Harting
Short Description HARTING Han 10A-STI-M, male insert, 10 contacts, screw termination, 10A, 250V, IP44
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Wire Gauge
0.14 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 500
Current Rating
10 Amperes
Voltage Rating
250 Volts
Contact Surface
Silver
Insert Material
Polycarbonate
Contact Material
Copper Alloy
Pollution Degree
3
Temperature Range
-40 to +125 Degrees Celsius
Contact Resistance
Less than 3 Milliohms
Number Of Contacts
10
Termination Method
Screw
Flammability Rating
V-0 according to UL94
Degree Of Protection
IP44 according to IEC 60529
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 Kilovolts

Full Description

The HARTING 09300100522 is a robust Han 10A-STI-M male insert, ideal for heavy-duty power connector applications. This insert features 10 contacts and utilizes a screw termination method, providing a secure and dependable electrical connection. With a current rating of 10A and a voltage rating of 250V, it is suitable for a wide range of industrial applications. The IP44 rating ensures protection against water spray from any direction, making it suitable for use in harsh environments. Supreme Components International is an authorised distributor of HARTING components, ensuring you receive a genuine and high-quality product. This insert is designed for easy installation and long-lasting performance.
