09 30 010 0423
Han 10A-STI-BVC-M
Datasheet
09 30 010 0423 Datasheet
Product Description
The HARTING 09300100423 is a robust Han 10A-STI-BVC-M heavy-duty power connector designed for reliable performance in industrial environments. Supreme Components International, an authorised distributor of HARTING electronic components, provides this connector to ensure secure and durable power connections. This connector is ideal for applications requiring high current carrying capacity and resistance to harsh conditions. Its rugged construction and reliable design make it suitable for use in machinery, automation, robotics, and power distribution systems. The Han 10A-STI-BVC-M connector offers easy installation and maintenance, reducing downtime and improving overall system efficiency. Trust HARTING and Supreme Components International for your heavy-duty power connection needs.
Technical Specifications
| Attribute | Description |
|---|---|
| Series | Han A |
| Material | Polycarbonate |
| Wire Gauge | 24 to 14 AWG |
| Current Rating | 10 Amperes |
| Voltage Rating | 230 Volts |
| Contact Plating | Silver |
| Contact Material | Copper Alloy |
| Temperature Range | Negative 40 Degrees Celsius to Positive 125 Degrees Celsius |
| Number Of Contacts | 10 |
| Termination Method | Screw |
| Flammability Rating | UL 94 V-0 |
