09 30 006 1296
HARTING Han B Insert, Male, 6+PE, 16A, Crimp Termination
Datasheet
09 30 006 1296 Datasheet
Product Description
The HARTING 09300061296 is a robust Han B series male insert specifically engineered for demanding heavy-duty power connector applications. This insert features 6+PE (protective earth) contacts, providing a reliable and safe power connection. With a 16A current rating, it's suitable for a wide range of industrial equipment and machinery. The crimp termination method ensures a secure and long-lasting electrical connection, minimizing downtime and maximizing performance. Supreme Components International is an authorised distributor of HARTING products, ensuring you receive a genuine, high-quality component. This insert is ideal for applications where durability and reliable power transmission are critical. Trust HARTING and Supreme Components International for your connectivity needs.
Technical Specifications
| Attribute | Description |
|---|---|
| Gender | Male |
| Series | HAN B |
| Material | Polycarbonate |
| Current Rating | 16 Amperes |
| Voltage Rating | 500 Volts |
| Pollution Degree | 3 |
| Contact Resistance | Less than 3 Milliohms |
| Number Of Contacts | 6 Plus Protective Earth |
| Termination Method | Crimp |
| Flammability Rating | UL 94 V-0 |
| Insulation Resistance | Greater than 10 to the power of 10 Ohms |
Ordering Information
| Attribute | Description |
|---|---|
| WEIGHT | 25.9 G |
