09 29 130 6504

Manufacturer Part Number (MPN) 09 29 130 6504
Manufacturer Harting
Short Description HARTING Han 3A-HMC-as-M20, axial screw termination, male insert
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Wire Gauge
0.2 to 2.5 square millimeters
Locking Type
For housings or hoods with single locking lever
Mating Cycles
Greater than or equal to 10000
Rated Current
16 Amperes
Rated Voltage
230 Volts
Material Group
IIla
Contact Surface
Silver
Contact Material
Copper alloy
Pollution Degree
3
Temperature Range
-40 to +125 degrees Celsius
Number Of Contacts
3 plus Protective Earth
Termination Method
Axial screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 Kilovolts
Flammability According To Ul94
V-0
Degree Of Protection According To Iec60529
IP20

Full Description

The HARTING 09 29 130 6504 is a Han 3A-HMC-as-M20 male insert, specifically engineered for heavy-duty power connector applications. This robust connector features axial screw termination, providing a secure and reliable connection for power transmission in harsh environments. Designed for industrial use, it is ideal for applications such as industrial machinery, automation systems, power distribution, and transportation. Supreme Components International is an authorised distributor of HARTING electronic components, ensuring that you receive a genuine, high-quality product. The Han 3A-HMC-as-M20 insert offers exceptional performance, durability, and ease of installation, making it a preferred choice for demanding industrial applications. Its robust design ensures long-term reliability and minimizes downtime. Trust Supreme Components International for all your HARTING connector needs.
