09 22 332 6919

Manufacturer Part Number (MPN) 09 22 332 6919
Manufacturer Harting
Short Description HARTING Han 3A-HMC-M-a2-LB-PG11, male insert, axial screw termination, 3+PE contacts, 16A, 500V, IP44
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Material
Polycarbonate
Wire Gauge
0.75 to 2.5 square millimeters
Locking Type
Screw Locking
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
500 Volts
Pollution Degree
3
Protection Degree
IP44
Temperature Range
-40 to +125 degrees Celsius
Contact Resistance
Less than 3 milliOhms
Number Of Contacts
3 plus Protective Earth
Termination Method
Axial Screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Flammability Rating Ul94
V-0

Ordering Information

Parameter
Value
Weight
25 g
Packaging Type
BOX

Full Description

The HARTING 09223326919 is a robust Han 3A-HMC-M-a2-LB-PG11 male insert, ideal for demanding heavy-duty power connector applications. This insert features axial screw termination, providing a secure and dependable electrical connection. With 3+PE contacts, it supports a current of 16A and a voltage of 500V. The IP44 rating ensures protection against solid objects and splashing water, making it suitable for various industrial environments. As an authorized distributor of HARTING components, Supreme Components International guarantees the authenticity and quality of this product. This insert is designed for easy installation and long-lasting performance, making it a reliable choice for your power connectivity needs.
