09 22 232 6824

Manufacturer Part Number (MPN) 09 22 232 6824
Manufacturer Harting
Short Description HARTING Han 3A-HMC-as-M20, axial screw termination, male insert, 3+PE contacts, 16A, 400V, IP44, crimp termination
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Material
Polycarbonate
Wire Gauge
0.14 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 10000
Rated Current
16 Amperes
Rated Voltage
400 Volts
Pollution Degree
3
Contact Resistance
Less than or equal to 3 milliOhms
Number Of Contacts
3 plus Protective Earth
Termination Method
Axial screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Operating Temperature
-40 to +125 degrees Celsius
Flammability Rating Ul94
V-0
Ingress Protection Rating
IP44

Full Description

The HARTING 09222326824 is a robust Han 3A-HMC-as-M20 male insert, specifically engineered for demanding heavy-duty power connector applications. This connector features 3+PE contacts, capable of handling 16A and 400V, ensuring reliable power transmission. Its IP44 rating provides protection against splashing water. The axial screw termination simplifies installation, while the design is optimized for crimp termination methods. Supreme Components International is an authorised distributor of HARTING, ensuring you receive a genuine, high-quality component. This connector is ideal for industrial environments requiring secure and dependable power connections.

Looking for more Harting connectors? [Click here to browse all Harting parts]
