Home Harting

09 22 132 7922

Manufacturer Part Number (MPN) 09 22 132 7922
Manufacturer Harting
Short Description HARTING Han 3A-HMC-M-a2-LB-PG11, male insert, axial screw termination, IP65/67, 32A, 500V, 2+PE contacts
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Wire Gauge
0.75 to 4 square millimeters
Mating Cycles
Greater than or equal to 10000
Rated Current
32 Amperes
Rated Voltage
500 Volts
Contact Surface
Silver
Insert Material
Polycarbonate
Contact Material
Copper alloy
Pollution Degree
3
Thermal Endurance
-40 to +125 degrees Celsius
Contact Resistance
Less than or equal to 1 milliohm
Number Of Contacts
2 plus Protective Earth
Termination Method
Axial screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Flammability According To Ul 94
V-0
Degree Of Protection According To Iec 60529
IP65/IP67

Full Description

Supreme Components International, an authorised distributor of HARTING components, presents the 09221327922, a high-performance male insert from the Han 3A-HMC series. This heavy-duty power connector is engineered for demanding industrial applications requiring reliable and secure connections. Featuring axial screw termination, installation is straightforward and ensures a robust electrical connection. The connector's IP65/67 rating provides excellent protection against dust and water, making it suitable for harsh environments. With a current rating of 32A and a voltage rating of 500V, this insert supports 2+PE contacts. The PG11 cable gland ensures proper cable sealing and strain relief. Trust HARTING quality and Supreme Components International's expertise for your connectivity needs.

Looking for more Harting connectors? [Click here to browse all Harting parts]

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.
