09 21 064 4602
HARTING Han Q 64 Housing, Cable to Cable, Size: 3 A, IP44, IP65, Die-cast aluminum, Powder-coated, RAL 7037 (dust grey)
Datasheet
09 21 064 4602 Datasheet
Product Description
The HARTING 09210644602 is a robust Han Q 64 series housing designed for heavy-duty power connector applications. This cable-to-cable housing, size 3 A, provides reliable connections in harsh environments. Its die-cast aluminum construction, coupled with a powder-coated finish in RAL 7037 (dust grey), offers excellent resistance to corrosion and wear. The housing meets IP44 and IP65 standards, ensuring protection against dust and water ingress. Ideal for industrial applications requiring secure and durable power connections. As an authorized distributor, Supreme Components International guarantees the authenticity and quality of this HARTING product. This housing is a critical component for creating reliable and long-lasting heavy-duty power connections.
Technical Specifications
| Attribute | Description |
|---|---|
| Size | Size 3 A |
| Series | Han Q Series |
| Locking Type | Double Locking Lever |
| Housing Color | Dust Grey |
| Mating Cycles | Greater than or equal to 500 |
| Connector Type | Hood |
| Housing Material | Die-Cast Aluminum |
| Pollution Degree | Degree 3 |
| Number Of Contacts | 64 Contacts |
| Cable Entry Direction | Straight |
| Insulation Resistance | Greater than 10^10 Ohms |
| Operating Temperature | From -40 to +125 Degrees Celsius |
| Ingress Protection Rating | IP44 and IP65 |
Ordering Information
| Attribute | Description |
|---|---|
| WEIGHT | 240 g |
| Packaging Type | BOX |
