09 21 064 2601
HARTING Han Q 64 Housing, Size: 3 A, Cable entry: axial, Material: Aluminium die-cast, Powder-coated, Degree of protection acc. to IEC 60529: IP65
Datasheet
09 21 064 2601 Datasheet
Product Description
The Harting 09210642601 is a Han Q 64 series housing, specifically designed for heavy-duty power connector applications. This housing, size 3 A, features an axial cable entry for convenient and secure cable management. Constructed from high-quality aluminum die-cast with a powder-coated finish, it offers exceptional durability and resistance to harsh environmental conditions. The IP65 rating according to IEC 60529 ensures protection against dust and water ingress, making it suitable for demanding industrial environments. Supreme Components International is an authorised distributor of Harting products, guaranteeing the authenticity and quality of this connector housing. This robust and reliable housing is an ideal choice for applications requiring secure and dependable power connections.
Technical Specifications
| Attribute | Description |
|---|---|
| Size | 3 A |
| Series | Han Q |
| Material | Aluminium die-cast |
| Top_Cable_Entry | No |
| Protection_Level | IP65 |
| Side_Cable_Entry | No |
| Locking_Mechanism | Single locking lever |
| Surface_Treatment | Powder-coated |
| Number_Of_Contacts | 64 |
| Flammability_Rating | V-0 |
| Cable_Entry_Direction | Axial |
| Threaded_Top_Cable_Entry | No |
| Threaded_Side_Cable_Entry | No |
| Operating_Temperature_Range | -40 ... +125 °C |
| Non_Threaded_Top_Cable_Entry | No |
| Non_Threaded_Side_Cable_Entry | No |
Ordering Information
| Attribute | Description |
|---|---|
| WEIGHT | 140 g |
| Packaging Type | BOX |
