Home Harting

09 20 010 0221

Manufacturer Part Number (MPN) 09 20 010 0221
Manufacturer Harting
Short Description HARTING Han 10A-STI-M, male insert, 10 contacts, screw termination, 10A, 250V, IP44
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Gender
Male
Wire Gauge
0.14 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 500
Current Rating
10 Amperes
Voltage Rating
250 Volts
Contact Surface
Silver
Insert Material
Polycarbonate
Contact Material
Copper Alloy
Pollution Degree
3
Temperature Range
-40 to +125 Degrees Celsius
Contact Resistance
Less than 3 Milliohms
Number Of Contacts
10
Termination Method
Screw
Flammability Rating
V-0 according to UL 94
Degree Of Protection
IP44 according to DIN EN 60529
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 Kilovolts

Full Description

The HARTING 09200100221 Han 10A-STI-M male insert is a crucial component for robust power connections in industrial settings. This insert features 10 contacts, utilizing a screw termination method for secure and dependable wiring. With a current rating of 10A and a voltage rating of 250V, it's designed to handle significant power loads. The IP44 protection rating ensures resistance to dust and splashing water, making it suitable for various environments. As an authorized distributor of HARTING products, Supreme Components International guarantees the authenticity and quality of this heavy-duty power connector insert. Choose HARTING for reliable and durable connectivity solutions. This insert is ideal for applications requiring a robust and secure power connection.

Looking for more Harting connectors? [Click here to browse all Harting parts]

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.
