09 20 003 1643

Manufacturer Part Number (MPN) 09 20 003 1643
Manufacturer Harting
Short Description HARTING Han 3A-STI-M-M20, Male insert, 3 contacts, screw termination, M20
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Series
HAN_3A
Material
Polycarbonate
Wire Gauge
0.75 to 6 Square Millimeters
Thread Size
M20
Mating Cycles
Greater than or equal to 500
Rated Current
40 Amperes
Rated Voltage
230 Volts
Pollution Degree
3
Contact Resistance
Less than 3 Milliohms
Number Of Contacts
3
Termination Method
Screw
Flammability Rating
UL 94 V-0
Insulation Resistance
Greater than 10 to the power of 10 Ohms

Ordering Information

Parameter
Value
Weight
22.5 G
Packaging Type
BOX

Full Description

The HARTING 09200031643 is a robust male insert specifically designed for heavy-duty power connector applications. Part of the Han 3A series, this insert features 3 contacts and utilizes a screw termination method, ensuring a secure and reliable electrical connection. The M20 threading provides compatibility with standard cable glands and enclosures. This insert is ideal for industrial environments where reliable power transmission is critical. Supreme Components International is an authorised distributor of HARTING electronic components, guaranteeing the authenticity and quality of this product. Trust Supreme Components International for your HARTING connector needs.
