Home Harting

09 20 003 0727

Manufacturer Part Number (MPN) 09 20 003 0727
Manufacturer Harting
Short Description HARTING Han 3A-STI-M-M20, Male insert, 3 contacts, M20 cable gland
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Gender
Male
Material
Polycarbonate
Wire Gauge
0.75 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 500
Rated Current
40 Amperes
Rated Voltage
230/400 Volts
Pollution Degree
3
Protection Degree
IP44/IP65/IP68 with Suitable Housing
Temperature Range
-40 to +125 Degrees Celsius
Contact Resistance
Less than 3 milliOhms
Number Of Contacts
3
Termination Method
Screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 Kilovolts
Flammability According To Ul94
V-0

Full Description

The HARTING 09200030727 is a robust and reliable Han 3A-STI-M-M20 male insert, specifically engineered for demanding heavy-duty power connector applications. This insert features 3 contacts, ensuring secure and efficient power transmission. The integrated M20 cable gland provides strain relief and cable protection, enhancing the overall durability of the connection. Supreme Components International is an authorised distributor of HARTING, guaranteeing that you receive a genuine, high-quality product. This insert is ideal for use in industrial machinery, automation systems, and other applications where a dependable power connection is critical. Its rugged design ensures long-lasting performance even in harsh environments. Choose HARTING for superior connectivity solutions.

Looking for more Harting connectors? [Click here to browse all Harting parts]

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.
