09 15 112 2722

Manufacturer Part Number (MPN) 09 15 112 2722
Manufacturer Harting
Short Description HARTING Han 1A-HBM-M12-M-PG9-axial, M12 connector, male, axial, M12-coding: D, Number of contacts: 4, shielded, Crimp termination
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Coding
D
Gender
Male
Shielded
Yes
Wire Gauge
26 to 20 AWG
Housing Color
Gray
Mating Cycles
Greater than or equal to 100
Rated Current
4 Amperes
Rated Voltage
63 Volts
Cable Diameter
4.5 to 9 Millimeters
Contact Surface
Gold
Contact Material
Copper Zinc
Housing Material
Polycarbonate
Pollution Degree
3
Temperature Range
-40 to +85 Degrees Celsius
Number Of Contacts
4
Termination Method
Crimp
Degree Of Protection
IP65/IP67
Insulation Resistance
Greater than 10^10 Ohms

Ordering Information

Parameter
Value
Weight
20 G
Packaging Type
BOX

Full Description

The HARTING 09151122722 is a robust and reliable M12 connector designed for industrial applications. Part of the Han 1A series, this male connector features axial mounting and D-coding, ensuring secure and error-free data transmission. With 4 contacts and shielding, it provides excellent signal integrity in demanding environments. The crimp termination method offers a durable and long-lasting connection. Supreme Components International is an authorised distributor of HARTING, guaranteeing the authenticity and quality of this product. This rectangular connector is ideal for use in automation, robotics, and other applications requiring a compact and dependable connection solution. The PG9 axial connection adds to its versatility.

Looking for more Harting connectors? [Click here to browse all Harting parts]
