09 14 921 2002
HARTING Han 1A-HBM-M20-M-BK, Rectangular Connector, Male, 2+PE Contacts, M20 Cable Gland
Datasheet
09 14 921 2002 Datasheet
Product Description
Supreme Components International, an authorised distributor of HARTING, presents the 09149212002, a high-performance rectangular connector from the Han 1A series. This male connector is designed for demanding industrial environments, providing a secure and dependable connection with its 2+PE contacts. The integrated M20 cable gland ensures proper cable management and strain relief. HARTING's reputation for quality and durability makes this connector a reliable choice for power and signal transmission. Choose Supreme Components International for genuine HARTING components and expert support. This connector is black in color.
Technical Specifications
| Attribute | Description |
|---|---|
| Gender | Male |
| Series | HAN_1A |
| Material | Polycarbonate |
| Cable Entry | M20 |
| Mating Cycles | Greater than or equal to 500 |
| Rated Current | 16 Amperes |
| Rated Voltage | 50 Volts |
| Pollution Degree | 3 |
| Temperature Range | -40 to +85 Degrees Celsius |
| Number Of Contacts | 2 + Protective Earth |
| Termination Method | Screw |
| Flammability Rating | UL 94-V0 |
| Insulation Resistance | Greater than 10^10 Ohms |
