Home Harting

09 14 208 3031

Manufacturer Part Number (MPN) 09 14 208 3031
Manufacturer Harting
Short Description HARTING Han 8 HPR female insert, 8 contacts, screw termination, IP68
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Gender
Female
Series
HAN_HPR
Wire Gauge
0.5 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
50 Volts
Contact Surface
Silver
Insert Material
Polycarbonate
Contact Material
Copper Alloy
Pollution Degree
3
Contact Resistance
Less than 3 milliOhms
Number Of Contacts
8
Termination Method
Screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Operating Temperature
-40 to +125 degrees Celsius
Flammability According To Ul94
V-0
Degree Of Protection According To Dinen60529
IP68

Full Description

Supreme Components International, an authorised distributor of HARTING products, presents the 09142083031, a robust Han 8 HPR female insert. This heavy-duty power connector insert features 8 contacts and utilizes a screw termination method for secure and lasting connections. Engineered for demanding industrial environments, the insert boasts an IP68 rating, providing exceptional protection against dust and water ingress. This makes it ideal for applications where reliability and durability are paramount. The HARTING Han 8 HPR series is known for its rugged construction and ability to withstand harsh conditions. Ensure optimal performance and longevity in your power connections with this high-quality female insert. Trust Supreme Components International for genuine HARTING components.
