09 14 005 2717

Manufacturer Part Number (MPN) 09 14 005 2717
Manufacturer Harting
Short Description HARTING Han 1A-STI-M-M20-PG7-S, Male connector insert, 5 contacts, M20/PG7 cable gland
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Series
HAN 1A
Material
Polycarbonate
Wire Gauge
0.14 to 2.5 Square Millimeters
Cable Entry
M20/PG7
Locking Type
Screw Locking
Mating Cycles
Greater Than or Equal to 500
Rated Current
16 Amperes
Rated Voltage
50 Volts
Pollution Degree
3
Protection Degree
IP20
Termination Style
Screw
Contact Resistance
Less Than 3 Milliohms
Number Of Contacts
5
Flammability Rating
UL 94 V-0
Insulation Resistance
Greater Than 10^10 Ohms
Operating Temperature
-30 to +80 Degrees Celsius

Full Description

The HARTING 09140052717 is a key component in the Han 1A series, offering a compact and reliable solution for rectangular connector needs. This male connector insert features 5 contacts, ensuring efficient power and signal transmission. The integrated M20/PG7 cable gland provides secure and strain-relieved cable termination, enhancing the overall durability and longevity of the connection. Supreme Components International is an authorised distributor of HARTING products, ensuring you receive genuine, high-quality components. This connector is well-suited for a variety of industrial applications where space is limited and reliable connections are crucial. Trust HARTING and Supreme Components International for your connectivity solutions.
