09 14 001 3111

Manufacturer Part Number (MPN) 09 14 001 3111
Manufacturer Harting
Short Description HARTING Han 1A-STI-M-M20, Male insert, 1+PE contacts, M20 cable gland
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Gender
Male
Wire Gauge
26 to 18 AWG
Cable Gland
M20
Mating Cycles
Greater than or equal to 500
Current Rating
16 Amperes
Voltage Rating
50 Volts
Contact Surface
Silver plated
Insert Material
Polyamide
Contact Material
Copper alloy
Pollution Degree
3
Temperature Range
-40 to +85 degrees Celsius
Number Of Contacts
1 plus Protective Earth
Termination Method
Screw
Flammability Rating
V-0 according to UL94
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Protection Degree Mating Side
IP20
Protection Degree Termination Side
IP20

Full Description

The HARTING 09 14 001 3111 is a robust and reliable Han 1A-STI-M-M20 male insert, specifically engineered for heavy-duty power connector applications. This insert features 1+PE (Protective Earth) contacts, ensuring safe and efficient power transmission. The integrated M20 cable gland provides secure cable termination and strain relief, enhancing the overall durability and longevity of the connection. Designed for use in harsh industrial environments, this Harting connector insert is ideal for applications such as industrial machinery, automation systems, power distribution, and other demanding power applications. Supreme Components International is an authorised distributor of Harting components, guaranteeing the authenticity and quality of this product. Trust Harting and Supreme Components International for your critical power connectivity needs.
