Home Harting

09 14 000 9915

Manufacturer Part Number (MPN) 09 14 000 9915
Manufacturer Harting
Short Description HARTING Han 1A-STI-M-M20-S, Male connector insert, M20 cable gland, screw termination
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Material
Polyamide (PA)
Wire Gauge
26-18 AWG
Mating Cycles
Greater than or equal to 500
Current Rating
16 Amperes
Voltage Rating
50 Volts
Pollution Degree
3
Protection Degree
IP20
Number Of Contacts
4
Termination Method
Screw
Flammability Rating
UL 94 V-0
Insulation Resistance
Greater than or equal to 10^10 Ohm
Operating Temperature
-30 Degrees Celsius to 80 Degrees Celsius
Rated Impulse Voltage
0.8 Kilovolts

Full Description

The Harting 09 14 000 9915 is a male connector insert belonging to the Han 1A series, known for its compact design and reliable performance. This rectangular connector features an M20 cable gland, providing secure cable entry and strain relief. The screw termination method ensures easy and robust wiring. As an authorized distributor of Harting electronic components, Supreme Components International guarantees the authenticity and quality of this product. The 09 14 000 9915 is suitable for a wide range of industrial applications where space is limited and reliable connectivity is crucial. Its robust construction and secure termination make it a dependable choice for demanding environments. Choose Harting for quality and durability.

Looking for more Harting connectors? [Click here to browse all Harting parts]

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.
