09 14 000 6256

Manufacturer Part Number (MPN) 09 14 000 6256
Manufacturer Harting
Short Description HARTING Han 1A-STI-M-M20-S, Male connector insert, M20 cable gland, straight, 4 contacts, screw termination
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Gender
Male
Series
Han 1A
Wire Gauge
26 to 18 AWG
Cable Gland
M20
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
50 Volts
Connector Type
Insert
Pollution Degree
3
Material Contacts
Copper alloy
Temperature Range
-40 Degrees Celsius to +85 Degrees Celsius
Contact Resistance
Less than 3 milliOhms
Material Insulator
Polyamide
Number Of Contacts
4
Termination Method
Screw
Flammability Rating
UL 94 V-0
Insulation Resistance
Greater than 10 to the power of 10 Ohms

Full Description

The Harting 09 14 000 6256 is a Han 1A-STI-M-M20-S male connector insert designed for various industrial applications. This rectangular connector features a straight configuration and an M20 cable gland, providing secure and strain-relieved cable entry. With 4 contacts, it's suitable for power and signal transmission. The screw termination method ensures a reliable and easy-to-maintain connection. As an authorized distributor of Harting components, Supreme Components International guarantees the authenticity and quality of this product. Ideal for applications requiring a compact and dependable connector solution.

Looking for more Harting connectors? [Click here to browse all Harting parts]
