09 12 002 3152

Manufacturer Part Number (MPN) 09 12 002 3152
Manufacturer Harting
Short Description HARTING Han 2 EE Inserts - Male, 2 Contacts, 80 A, 690 V, Crimp Termination
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Series
HAN 2 EE
Material
Polycarbonate
Wiregauge
18 to 8 AWG
Currentrating
80 Amperes
Voltagerating
690 Volts
Pollutiondegree
3
Numberofcontacts
2
Terminationmethod
Crimp
Flammabilityrating
UL 94 V-0
Insulationresistance
Greater than 10 to the power of 10 Ohm

Ordering Information

Parameter
Value
Weight
22.7 g
Packaging Type
BOX

Full Description

The HARTING 09120023152 is a robust Han 2 EE series male insert specifically engineered for heavy-duty power connector applications. This insert features 2 contacts, capable of handling a current of 80 A and a voltage of 690 V. The crimp termination method ensures a secure and dependable electrical connection, making it suitable for harsh industrial environments. This insert is part of the Han series, known for its modularity and reliability in power and signal transmission. Supreme Components International is an authorised distributor of HARTING products, ensuring you receive a genuine, high-quality component. Trust in HARTING's engineering excellence for your critical power connectivity needs.

Looking for more Harting connectors? [Click here to browse all Harting parts]
