09 07 001 0225 100
HARTING Han Q Series Insert, Male, 1 Position, 70 A, 690 V, Screw Termination
Datasheet
09 07 001 0225 100 Datasheet
Product Description
Supreme Components International, an authorised distributor of Harting products, presents the 09070010225100, a robust male insert from the Han Q series. This heavy-duty power connector is engineered for reliable performance in harsh industrial settings. Featuring a single position, it supports a current rating of 70A and a voltage rating of 690V. The screw termination method provides a secure and dependable connection, minimizing downtime and ensuring efficient power transmission. The Han Q series is known for its durability and resistance to environmental factors, making it suitable for demanding applications such as industrial machinery, power distribution, and automation systems. Trust Supreme Components International for your Harting connector needs.
Technical Specifications
| Attribute | Description |
|---|---|
| Gender | Male |
| Series | Han Q |
| Material | Polycarbonate |
| Wire Gauge | 1.5 square millimeters to 10 square millimeters |
| Current Rating | 70 Amperes |
| Voltage Rating | 690 Volts |
| Number Of Contacts | 1 |
| Termination Method | Screw |
| Flammability Rating | UL 94 V-0 |
