09 06 232 6836

Manufacturer Part Number (MPN) 09 06 232 6836
Manufacturer Harting
Short Description HARTING Han 3A-HMC-M-a2-LB-PG11, Male insert, Axial screw termination, PG11
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Wire Gauge
0.75 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
230 Volts
Clamping Range
PG11
Contact Surface
Silver
Insert Material
Polycarbonate
Contact Material
Copper alloy
Pollution Degree
3
Contact Resistance
Less than or equal to 3 milliOhms
Number Of Contacts
2 plus Protective Earth
Termination Method
Axial screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 kilovolts
Flammability According To Ul94
V-0
Degree Of Protection According To Dinen60529
IP20

Full Description

The Harting 09062326836 is a Han 3A-HMC-M-a2-LB-PG11 male insert, specifically engineered for demanding heavy-duty power connector applications. This robust connector insert features axial screw termination, providing a secure and reliable electrical connection. The PG11 thread ensures compatibility with standard cable glands and enclosures. Designed for industrial environments, this Harting connector insert offers exceptional performance and durability. Supreme Components International is an authorised distributor of Harting electronic components, ensuring you receive a genuine, high-quality product. Trust Harting and Supreme Components International for your critical power connection needs. This insert is suitable for various applications requiring a dependable and robust power connection solution.

Looking for more Harting connectors? [Click here to browse all Harting parts]
