09 06 232 2832

Manufacturer Part Number (MPN) 09 06 232 2832
Manufacturer Harting
Short Description HARTING Han 3A-HMC-M-a2-LB-PG11, male insert, axial screw termination, 32 A, 250 V, PG11
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Wire Gauge
0.75 to 4 square millimeters
Mating Cycles
Greater than or equal to 10000
Rated Current
32 Amperes
Rated Voltage
250 Volts
Clamping Range
PG11
Contact Surface
Silver
Insert Material
Polycarbonate
Contact Material
Copper alloy
Pollution Degree
3
Termination Type
Axial screw termination
Contact Resistance
Less than or equal to 1 milliohm
Number Of Contacts
2 plus Protective Earth
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 Kilovolts
Flammability Class According To Ul94
V-0
Degree Of Protection According To Iec60529
IP20

Full Description

The HARTING 09062322832 is a Han 3A-HMC-M-a2-LB-PG11 male insert, specifically engineered for heavy-duty power connector applications. This robust connector features axial screw termination, simplifying the wiring process and ensuring a secure connection. With a current rating of 32 A and a voltage rating of 250 V, it is suitable for a wide range of industrial applications. The PG11 gland provides reliable cable entry and strain relief. Supreme Components International is an authorised distributor of HARTING, guaranteeing the authenticity and quality of this product. This connector is ideal for use in industrial machinery, power distribution systems, and other demanding environments where reliable power connections are critical. Its durable construction ensures long-lasting performance and resistance to harsh conditions.
