09 06 232 2821

Manufacturer Part Number (MPN) 09 06 232 2821
Manufacturer Harting
Short Description HARTING Han 3A-HMC-M-a2-LB-PG11, Male insert, 3+PE contacts, 16A, Screw termination, IP44, HMC
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Series
Han 3A
Material
Polycarbonate
Wire Gauge
0.75 to 2.5 square millimeters
Locking Type
For Han A/3A Hoods/Housings
Current Rating
16 Amperes
Voltage Rating
230/400 Volts
Pollution Degree
3
Protection Degree
IP44
Contact Resistance
Less than or equal to 3 milliOhms
Number Of Contacts
3 plus PE
Termination Method
Screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 kilovolts

Full Description

The HARTING 09062322821 is a robust Han 3A-HMC-M-a2-LB-PG11 male insert, specifically engineered for heavy-duty power connector applications. This insert features 3+PE contacts, capable of handling a current of 16A. The screw termination method ensures a reliable and secure electrical connection. Its IP44 rating provides protection against water splashing from any direction, making it suitable for use in environments where moisture is present. As an authorized distributor of HARTING products, Supreme Components International guarantees the authenticity and quality of this component. This connector is designed to withstand harsh industrial conditions and provide long-lasting performance. The HMC (High Mating Cycle) design ensures durability even with frequent connections and disconnections. Trust HARTING and Supreme Components International for your demanding connectivity needs.
