HARTING Han B Insert, Male, 48+PE, Crimp Termination, 16A, 500V
Datasheet
09 06 148 6951 Datasheet
Product Description
The HARTING 09061486951 is a robust Han B series male insert specifically engineered for heavy-duty power connector solutions. This insert features 48+PE contacts, providing ample connections for complex power and signal requirements. The crimp termination method ensures a secure and reliable connection, minimizing downtime and maximizing performance. Rated for 16A and 500V, this insert is suitable for a wide range of industrial applications. The polycarbonate construction offers excellent durability and resistance to harsh environmental conditions. Supreme Components International is an authorised distributor of HARTING, ensuring you receive a genuine, high-quality product. This insert is perfect for use in industrial machinery, power distribution systems, and other demanding applications where reliable power connectivity is crucial.
Technical Specifications
| Attribute | Description |
|---|---|
| Gender | Male |
| Series | HAN B |
| Material | Polycarbonate |
| Wire Gauge | 0.14 to 4 square millimeters |
| Locking Type | Central Locking |
| Current Rating | 16 Amperes |
| Voltage Rating | 500 Volts |
| Pollution Degree | 3 |
| Contact Resistance | Less than or equal to 1 milliOhm |
| Number Of Contacts | 48 plus PE |
| Termination Method | Crimp |
| Flammability Rating | UL 94 V-0 |
| Insulation Resistance | Greater than 10 to the power of 10 Ohms |
| Rated Impulse Voltage | 6 kiloVolts |
