09 06 115 2911
HARTING Han 16 HPR EasyCon Hood, Cable Entry: 1 x M25, Size: 16 HPR, Material: Die-cast aluminum alloy, Protection degree: IP68, IP69 / IP69K
Datasheet
09 06 115 2911 Datasheet
Product Description
The HARTING 09061152911 is a robust Han 16 HPR EasyCon hood, ideal for demanding heavy-duty power connector applications. This hood features a single M25 cable entry point and is meticulously crafted from high-quality die-cast aluminum alloy, ensuring exceptional durability and resistance to corrosion. Its design provides superior protection against environmental factors, boasting IP68, IP69, and IP69K protection degrees. This makes it suitable for use in challenging industrial settings where exposure to dust, water, and high-pressure cleaning is common. Supreme Components International is an authorised distributor of HARTING products, guaranteeing the authenticity and reliability of this essential component. The 09061152911 is part of the Han HPR series, known for its ruggedness and ease of use.
Technical Specifications
| Attribute | Description |
|---|---|
| Series | Han HPR |
| Material | Die-cast aluminum alloy |
| Hood Size | 16 HPR |
| Cable Entry | M25 |
| Locking Type | Double locking lever |
| Pollution Degree | 3 |
| Protection Degree | IP68, IP69 / IP69K |
| Corrosion Resistance | Salt spray test: > 500 hours |
| Operating Temperature | -40 to +125 degrees Celsius |
| Flammability Rating Ul94 | V-0 |
