09 06 001 9919

Harting Logo
Manufacturer Part Number (MPN) 09 06 001 9919
Manufacturer Harting
Short Description HARTING Han 1A-STI-M-M20-SC-C, Male connector insert, M20 cable gland, Crimp termination, 1+PE poles
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Wiregauge
28 to 14 AWG
Cablegland
M20
Matingcycles
Greater than or equal to 500
Ratedcurrent
16 Amperes
Ratedvoltage
50 Volts
Housingmaterial
Polyamide (PA)
Pollutiondegree
3
Numberofcontacts
1 plus PE (Protective Earth)
Protectiondegree
IP20 (when mated)
Temperaturerange
-40 to +85 Degrees Celsius
Contactresistance
Less than or equal to 3 milliOhms
Terminationmethod
Crimp
Flammabilityrating
V-0 according to UL 94
Mechanicaloperation
Greater than or equal to 500 mating cycles
Insulationresistance
Greater than 10 to the power of 10 Ohms

Full Description

The Harting 09060019919 is a Han 1A-STI-M-M20-SC-C male connector insert, part of the renowned Han 1A series known for its compact design and reliable performance. This connector features an M20 cable gland, providing secure and strain-relieved cable entry. The crimp termination method ensures quick and easy wiring, saving valuable installation time. With 1+PE poles, it's suitable for power and grounding connections. Supreme Components International is an authorised distributor of Harting, ensuring you receive a genuine, high-quality product. Ideal for industrial automation, robotics, and other applications requiring robust and dependable connectivity.

Looking for more Harting connectors? [Click here to browse all Harting parts]
