09 04 632 2951
HARTING Han 3A-HMC-M-a2-LB-PG11, male insert, axial screw termination, IP65/67, 32A, 500V, 2+PE contacts
Datasheet
09 04 632 2951 Datasheet
Product Description
The HARTING 09046322951 is a robust Han 3A-HMC-M-a2-LB-PG11 male insert, ideal for demanding heavy-duty power connector applications. This connector features axial screw termination, providing a reliable and secure electrical connection. With an IP65/67 rating, it offers excellent protection against dust and water ingress, making it suitable for harsh environments. It is designed to handle 32A and 500V, and includes 2+PE contacts. This insert is part of the Han 3A series, known for its compact design and high performance. Supreme Components International is an authorized distributor of HARTING, guaranteeing the authenticity and quality of this product. Trust SCI for your HARTING connector needs.
Technical Specifications
| Attribute | Description |
|---|---|
| Wire Gauge | 0.75 to 4 square millimeters |
| Mating Cycles | Greater than or equal to 500 |
| Rated Current | 32 Amperes |
| Rated Voltage | 500 Volts |
| Reachcompliant | Yes |
| Ro Hscompliant | Yes |
| Contact Surface | Silver |
| Insert Material | Polycarbonate |
| Contact Material | Copper alloy |
| Pollution Degree | 3 |
| Contact Resistance | Less than 1 milliOhm |
| Number Of Contacts | 2 plus Protective Earth |
| Termination Method | Axial screw |
| Flammability Rating | V-0 according to UL 94 |
| Insulation Resistance | Greater than 10 to the power of 10 Ohms |
| Operating Temperature | Minus 40 to plus 125 degrees Celsius |
| Ingress Protection Rating | IP65 and IP67 |
