09 04 132 2921

Manufacturer Part Number (MPN) 09 04 132 2921
Manufacturer Harting
Short Description HARTING Han 3A-HMC-M-a2-LB-PG11, male insert, axial screw termination, 3+PE contacts, 16A, 500V, IP44
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Material
Polycarbonate
Wire Gauge
0.75 to 2.5 square millimeters
Locking Type
For Han 3A housings
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
500 Volts
Connection Type
Axial screw
Pollution Degree
3
Protection Degree
IP44
Temperature Range
-40 to +125 degrees Celsius
Contact Resistance
Less than or equal to 3 milliOhms
Number Of Contacts
3 plus Protective Earth
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Flammability According To Ul94
V-0

Full Description

The HARTING 09041322921 is a robust Han 3A-HMC-M-a2-LB-PG11 male insert, ideal for demanding heavy-duty power connector applications. This insert features axial screw termination, providing a reliable and secure connection for your power needs. With 3+PE contacts, it supports a current of 16A and a voltage of 500V. The IP44 rating ensures protection against solid objects and splashing water, making it suitable for various industrial environments. As an authorised distributor of HARTING components, Supreme Components International guarantees the authenticity and quality of this product. Trust HARTING and Supreme Components International for your critical connectivity solutions.
