09 03 296 6821
HARTING Han 3A-HMC-as-M20, axial screw termination, male insert, 16A, 50V, 3+PE contacts
Datasheet
09 03 296 6821 Datasheet
Product Description
The HARTING 09032966821 is a robust Han 3A-HMC-as-M20 male insert, specifically engineered for demanding heavy-duty power connector applications. This insert features axial screw termination, providing a secure and reliable connection point for wires. With a current rating of 16A and a voltage rating of 50V, it is suitable for a wide range of industrial power applications. The 3+PE (Protective Earth) contacts ensure safe and efficient power transmission, minimizing the risk of electrical hazards. As an authorized distributor of HARTING components, Supreme Components International guarantees the authenticity and quality of this product. This insert is ideal for use in machinery, automation systems, and other industrial equipment where reliable power connectivity is crucial. Its durable construction and high-performance capabilities make it a dependable choice for demanding environments.
Technical Specifications
| Attribute | Description |
|---|---|
| Material | Polycarbonate |
| Wire Gauge | 0.14 to 2.5 square millimeters |
| Locking Type | For Han 3A Hoods and Housings |
| Mating Cycles | Greater than or equal to 500 |
| Rated Current | 16 Amperes |
| Rated Voltage | 50 Volts |
| Pollution Degree | 3 |
| Temperature Range | -40 to +125 degrees Celsius |
| Contact Resistance | Less than or equal to 3 milliohms |
| Number Of Contacts | 3 plus Protective Earth |
| Termination Method | Axial Screw |
| Insulation Resistance | Greater than 10 to the power of 10 Ohms |
