09 03 260 6401

Manufacturer Part Number (MPN) 09 03 260 6401
Manufacturer Harting
Short Description HARTING Han 16A Hood, Size: 3 A, Cable entry: Axial, Material: Die-cast aluminum, Degree of protection acc. to IEC 60529: IP65 / IP67
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Size
Size 3 A
Series
Han A Series
Surface
Powder-coated, grey color
Material
Die-cast aluminum material
Cable Entry
Axial cable entry
Locking Type
Single locking lever type
Mating Cycles
Greater than or equal to 500
Clamping Range
6 to 12 mm
Nominal Current
16 Amperes
Nominal Voltage
50 Volts
Pollution Degree
Pollution Degree 3
Number Of Entries
1 Entry
Contact Resistance
Less than or equal to 1 mOhm
Degree Of Protection
IP65 / IP67
Limiting Temperature
Up to +125 Degrees Celsius
Insulation Resistance
Greater than 10^10 Ohm
Operation Temperature
-40 to +125 Degrees Celsius

Ordering Information

Parameter
Value
Weight
60 g
Packaging Type
BOX

Full Description

Supreme Components International, an authorised distributor of Harting products, presents the 09032606401, a Han 16A hood engineered for demanding heavy-duty power connector applications. This robust hood, part of Harting's renowned Han series, features a die-cast aluminum construction, providing exceptional durability and resistance to harsh environmental conditions. The axial cable entry simplifies installation, while the IP65/IP67 degree of protection, according to IEC 60529, ensures reliable performance in wet and dusty environments. Ideal for industrial machinery, automation systems, and power distribution applications, this Size 3 A hood offers a secure and dependable connection. Trust Supreme Components International for your Harting connector needs.
