09 03 232 6834

Manufacturer Part Number (MPN) 09 03 232 6834
Manufacturer Harting
Short Description HARTING Han 3A-HMC-M-a2-LB-PG11, Male insert, Axial screw termination, 3+PE contacts, 16A, 500V, PG11
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Wire Gauge
0.75 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 10000
Clamping Range
PG11
Current Rating
16 Amperes
Voltage Rating
500 Volts
Contact Plating
Silver
Locking Element
Yes
Contact Material
Copper alloy
Inserts Material
Polycarbonate
Pollution Degree
3
Protection Degree
IP44
Number Of Contacts
3 plus Protective Earth
Termination Method
Axial screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Flammability According To Ul94
V-0

Full Description

The Harting 09032326834 is a robust Han 3A-HMC-M-a2-LB-PG11 male insert, ideal for demanding heavy-duty power connector applications. This insert features axial screw termination, providing a secure and dependable electrical connection. With 3+PE contacts, it supports a current rating of 16A and a voltage rating of 500V. The PG11 cable gland ensures proper sealing and strain relief. This insert is designed for easy installation and long-lasting performance in harsh environments. As an authorized distributor of Harting components, Supreme Components International ensures you receive a genuine, high-quality product. Trust Harting and Supreme Components International for your critical connectivity needs.
