02 54 903 1301
HARTING Han 3A-STI-M-M20 - Male insert, 3+PE contacts, M20 cable gland, screw termination.
Datasheet
02 54 903 1301 Datasheet
Product Description
The HARTING 02 54 903 1301 is a robust Han 3A-STI-M-M20 male insert, specifically engineered for demanding heavy-duty power connector applications. This insert features 3+PE contacts, providing a secure and reliable connection for power and grounding. The integrated M20 cable gland offers strain relief and protection for the cable entry. Screw termination ensures easy and secure wiring. Supreme Components International is an authorised distributor of HARTING components, ensuring you receive a genuine and high-quality product. This insert is ideal for use in industrial machinery, automation systems, and other applications where a durable and dependable power connection is essential. Its rugged design and reliable performance make it a perfect choice for harsh environments.
Technical Specifications
| Attribute | Description |
|---|---|
| Gender | Male |
| Series | Han 3A |
| Material | Polycarbonate |
| Wire Gauge | 0.75 to 2.5 square millimeters |
| Cable Gland | M20 |
| Mating Cycles | Greater than or equal to 500 |
| Rated Current | 16 Amperes |
| Rated Voltage | 230/400 Volts |
| Pollution Degree | 3 |
| Contact Resistance | Less than 3 milliOhms |
| Number Of Contacts | 3 plus Protective Earth |
| Termination Method | Screw |
| Insulation Resistance | Greater than 10 to the power of 10 Ohms |
| Flammability Class According To Ul94 | V-0 |
